Akulon® K224-LGM35

15% Glass Reinforced, 25% Mineral Reinforced, Improved UV-stability

Back to results

General Information

Akulon® is our family of high performance polyamide 6 and polyamide 66 materials, used by customers across the world in applications ranging from automotive, electronics & electrical, to furniture and packaging.
We offer Akulon® grades for injection molding, blow molding and extrusion (including barrier film, stock shapes, convoluted tubes, and mono and multi filament).
In molded parts the material offers an excellent balance of easy design and processing with outstanding mechanical properties over a wide temperature range and in diverse conditions. Meanwhile for extrusion the strength, resilience and easy processing of Akulon® sets the market standards.
Special features
  • U.V. stabilized or stable to weather
General Document
Regulatory Affairs
  • Absence Declaration BNST2023-11-16
  • Absence Declaration Biocidal Products2023-11-16
  • Absence Declaration DMF (2009/251/EC: Dimethylfumarate)2023-11-16
  • Absence Declaration ELV (2000/53/EC: Heavy metals)2024-02-15
  • Absence Declaration EPA 20 High Priority Substances 20192023-11-16
  • Absence Declaration Food Allergens2023-11-16
  • Absence Declaration NMP (N-Methylpyrrolidone)2023-11-16
  • Absence Declaration Nano Materials2023-11-16
  • Absence Declaration Ozone Depleting Chemicals2024-06-27
  • Absence Declaration PAH (Polycyclic Aromatic Hydrocarbons)2023-11-16
  • Absence Declaration PBT chemicals under TSCA section 6(h)2023-11-16
  • Absence Declaration PFAS2024-03-05
  • Absence Declaration POPs (Persistent Organic Pollutants)2024-09-04
  • Absence Declaration Phthalates (2005/84/EC: DEHP, DBP, BBP,DINP,DIDP, DNOP)2023-11-16
  • Absence Declaration Red Phosphorus2023-11-16
  • Absence Declaration opBDE (2003/11/EC: Octa- / Pentabromodiphenylether)2023-11-16
  • Compliance Statement EU Sanctions and Embargos2024-05-16
  • Conflict minerals declaration (EICC, GeSI)2024-05-15
  • Deforestation Statement, Regulation (EU) 2023/1115 (EUDR)2024-09-19
  • Packaging Declaration EU Decision 97/129/EC (labelling)2024-04-17
  • Packaging, Packaging Waste and CONEG declaration (94/62/EC)2021-12-06
  • REACH Registration Statement2024-03-27
  • REACH STATEMENT KOREA2023-11-16
  • REACH STATEMENT TURKYE2023-11-16
  • RoHS Statement (2011/65/EC: Heavy metals)2024-02-01
  • SVHC, REACH Annex XIV and –XVII Statement2024-11-08
Processing technology
Injection Molding
Design challenge
Degradation & Stability | UV stability
Automotive OEM
FIAT CHRYSLER, FORD, GM
OEM Specification
FCA-MS50017(MS-DB-41)-CPN3326-(2017-02)
FCA-MS50017(MS-DB-41)-CPN3781-(2017-02)
FCA-MS50017(MS-DB-41)-CPN4759-(2017-02)
FCA-MS50017(MS-DB-41)-CPN4760-(2017-02)
GMW16280P-PA6-M25GF15
WSS-M4D822-A2
Applications
Have a question? Contact us

Rheological properties

Melt volume-flow rate
17
cm³/10min
Temperature
275
°C
Load
5
kg
Melt flow index MFI
14
g/10min
MFI test temperature
275
°C
MFI test load
5
kg
Molding shrinkage (parallel)
0.38
%
Molding shrinkage (normal)
0.88
%

Mechanical properties

Tensile modulus
10500
MPa
Tensile modulus (-40°C)
11000
MPa
Stress at break
135
MPa
Stress at break (-40°C)
180
MPa
Strain at break
2.4
%
Strain at break (-40°C)
2.5
%
Flexural modulus
10500
MPa
Flexural strength
195
MPa
Charpy impact strength (+23°C)
40
kJ/m²
Charpy impact strength (-30°C)
40
kJ/m²
Charpy notched impact strength (+23°C)
4.5
kJ/m²
Charpy notched impact strength (-30°C)
3.5
kJ/m²

Thermal properties

Melting temperature (10°C/min)
220
°C
Temp. of deflection under load (1.80 MPa)
205
°C
Temp. of deflection under load (0.45 MPa)
215
°C
Coeff. of linear therm. expansion (parallel)
0.35
E-4/°C
Coeff. of linear therm. expansion (normal)
0.5
E-4/°C

Electrical properties

Relative permittivity (100Hz)
3.5
-
Relative permittivity (1 MHz)
3.3
-
Dissipation factor (100 Hz)
50
E-4
Dissipation factor (1 MHz)
140
E-4
Volume resistivity
1E12
Ohm*m
Surface resistivity
Ohm
Electric strength
35
kV/mm

Other properties

Humidity absorption
1.7
%
Density
1490
kg/m³

Applications

Grill Handles

Industry
Consumer goods
Material
Akulon® PA6 is a reliable solution for grill handles compared to metals as no corrosion protection coating is needed with PA6. Akulon UltraFlow PA6 yields a better surface appearance than PA66 (even at 50% to 60% GF). Akulon L types of PA6 yield good UV-resistance. Akulon UltraFlow PA6 enables thin-walled designs.}
More information

Roof Racks

Industry
Automotive
Material
  • •} Reliable
  • •} High heat resistance
  • •} Great surface appearance
  • •} Lightweight
  • •} Cost effective
  • •} High flowability enables thin wall designs
}
